November 2006
12 AL4000 Light Tower Part No. 833002 Rev A
TRANSPORT & TOWING
1. Using the front leveling jack, securely attach the light tower to the transporting vehicle.
2. Insure that the coupler is properly secured to the towing vehicle and attach the safety
chains.
ALWAYS USE THE PROPER TRAILER HITCH AND SAFETY
CHAINS. OBEY ALL LOCAL OR STATE D.O.T. LAWS WHEN
TOWING A LIGHT TOWER.
FAILURE TO PROPERLY SECURE THE TRAILER TO THE
TOWING VEHICLE MAY RESULT IN SERIOUS INJURY OR
DEATH.
3. Retract and rotate the front leveling jack into its stowed position.
4. Check the tires for proper inflation (32psi) and verify the lug nuts are tight.
5. Position all outriggers and jacks into the stowed or travel position.
6. Verify that the fixtures are secure and ready for transport.
7. Secure all loose locking pins and retainers.
8. Make sure all doors are closed and tightly locked.
9. Remove tire chocks.
Towing of a Terex light tower is approved with the light fix-
tures in place on the crosshead assembly for all off road
terrain and highway towing as long as the following speed
limits are followed:
Highway towing - 60 MPH max
Off road towing - 10 MPH max
Severe damage may occur from excessive speeds. Damage
created by abuse will void the manufacturer’s warranty.
