November 2006
Part No. 833002 Rev A AL4000 Light Tower 19
7. Start the Engine/Generator Set
A. Ensure the circuit breakers are turned “OFF”. This prevents the engine from
starting under load and prevents electrical equipment from being subjected to
improper voltage and frequency.
B. Check the oil, fuel, and coolant levels. If the fuel tank is empty, it may be necessary to
bleed the fuel line after filling the tank (see engine instruction book for procedure).
C. Turn the ignition switch to the “ACC” position (see diagram below). Press the preheat
push-button for a
maximum of 20 SECONDS. Do not engage the preheat
button longer than the time specified or damage may occur.
D. Turn the ignition switch to the “START” position to engage the engine. After the engine
starts, release the switch so that it returns to the “RUN” position. Let the engine come
up to speed and stabilize (review the engine operating procedures in the manufactur-
ers handbook). Note: If engine will not start, leave switch in run position for additional
10-20 seconds to completely prime the fuel system. Then repeat step “C” and start
engine.
E. Turn on the main circuit breaker.
8. Turn on the floodlights:
A. Turn the circuit breakers “ON” and ensure all lamps come on. Allow a minimum of
two (2) minutes for lamps to reach full luminance.
B. If required, rotate the tower to aim the lights as desired. Tighten the tower rotating
locking bolt.
C. Adjust the tower vertically and adjust lighting direction of individual fixtures if required.
9. Turn off the floodlights:
OPERATING INSTRUCTIONS
