November 2006
Part No. 833002 Rev A AL4000 Light Tower 57
ITEM # PART # DESCRIPTION QTY.
1 841050 AXLE 3500LB 38.5 SPRING CENTER 1
2 834267 U-BOLT KIT - 3500# 2
3 834229 SEAL, HYDRAULIC 2
4 834226 INNER BEARING 2
5 834220 HUB ASSY HT1000 3500LB 2
6 834227 OUTER BEARING 2
7 834225 SEAL,GREASE 2
8 834250 SPINDLE NUT 2
9 834228 GREASE CAP 2
10 841060 TIRE & WHEEL MOUNTED P205/75-15 LOAD B2 2
11 840376 AXLE WHEEL NUT 10
12 840395 AXLE SPRING NUT 6
13 840392 AXLE REAR HANGER 2
14 840394 AXLE SPRING BOLT 6
15 841473 AXLE SHACKLE 2
16 834246 SPRING EYE BUSHING 4
17 834211 SPRING FOR AXLE 4-LEAF 2
18 841051 AXLE FRONT HANGER 2
19 841855 AXLE HUB,HYD. & PARK BRAKE,L/H 1
20 841860 AXLE HUB,HYD. & PARK BRAKE,R/H 1
21 841870 AXLE HUB,ELECTRIC&PARK BRAKE,LH 1
22 841875 AXLE HUB,ELECTRIC&PARK BRAKE,RH 1
23 841220 COUPLER,SURGE 3"RING 1
24 841500 COUPLER,SURGE,2"BALL 1
25 840396 AXLE WHEEL NUT 10
