November 2006
Part No. 833002 Rev A AL4000 Light Tower 61
ITEM # PART # DESCRIPTION QTY.
1 116180 REAR TOWER SUPPORT, COMPLETE ASSEMBLY 1
2 790540 PIN QUICK1/4X1.75 ZP 1
3 720220 BUMPER REAR TOWER SUPPORT 1
4 123680 PIN W/RING 3/4X11 1
5 124460 REAR TOWER SUPPORT 1
6 796610 HINGE PIANO 1.5X51.75 2
7 188560 CABINET DOOR PANEL 1
8 796432 GAS SPRING SHORT BRACKET WITH BALL 8
9 992040 RIVET POP 3/16X.602 16
10 796436 GAS SPRING 16", 60 LB. 4
11 188550-2 CABINET TOP PANEL 1
12 794940 PLUG PLASTIC 1
13 189796 HASP,CABINET DOOR, 2
14 188560 CABINET DOOR PANEL 1
15 790940 HANDLE 5.75 CHROME PLATED 2
16 124420 GROUND ROD STORAGE TUBE 1
17 176380 COVER PLATE,CABINET 2
18 113399 GROUND ROD LT.TWR. 1
19 995050 SCREW,#10-32NFX3/4 4
20 R980300 WASHER,FLAT,#10 4
21 995420 NUT,LOCK NYLON INSERT #10-32 HX M/S JAM 4
22 990670 RIVET POP 3/16X1/2 36
