November 2006
Part No. 833002 Rev A AL4000 Light Tower 71
ITEM # PART # DESCRIPTION QTY.
1 124490 TOWER BASE 1
2 REFER TO WINCH DRAWING ON NEXT PAGE
3 981450 SCREW,3/8-16NCX1-1/2 2
4 990470 WASHER LOCK 3/8 2
5 990080 WASHER FLAT 3/8 2
6 990140 SCREW 1/4-20NCX2 1
7 990150 NUT LOCK NYLON INSERT 1/4-20NC GR 2 ZP 1
8 124480 WINCH HANDLE W/TUBE 1
9 853670 DECAL: CRUSH AREA 1
10 850090 DECAL: CAUTION STAND CLEAR OF TOWER. 1
11 850105 DECAL: DANGER DO NOT PULL THE VERTICAL 1
12 109517 KIT:LOCK SLIDE PIN includes items 13-21 1
13 113362 PIN,LOCK SLIDE includes items 14-15 1
14 990760 PIN BRIDGE .0915 X 1-7/8 S/S 1
15 120640 PIN W/RING 5/16 X 1-5/8 1
16 990660 ROLL PIN 1/4 X1-5/8 1
17 980340 SCREW,5/16-18NCX1/2 1
18 790710 SPRING COIL 1/2 X2.25 1
19 990650 COTTER PIN 1/8X1 SS 1
20 171636 LOCK PIN SHELL 1
21 171640 LOCK SPRING SHELL 1
22 995760 CLEVIS PIN STAINLESS STEEL 1/2 X3-1/2 1
23 184510 SHEAVE SPOOL 3 X 2-1/2 1
24 990650 COTTER PIN 1/8X1 SS 1
25 186360 BUMPER PAD 1
26 995420 NUT,LOCK NYLON INSERT #10-32 HX M/S JAM 2
27 R980300 WASHER,FLAT,#10 4
28 995050 SCREW,#10-32NFX3/4 LOW HD SHCS ZINC 2
29 193750 SPRING LEAF CUSTOM KICKOUT 1
30 990200 NUT LOCK NYLON INSERT 1/2-13NC GR 2 ZPIN 1
31 981920 SCREW 1/2-13NCX3 HHC GR 8 Y-ZINC 1
To Next Page
