Part No. 833002 Rev A AL4000 Light Tower 79
ITEM # PART # DESCRIPTION QTY.
1 853294 DECAL: AL/RL CONTROL BOX AC "POWER & LIGHT" 1
2 683680 BREAKER 2P 30A 240V 1
3 186546 CONTROL BOX,FACE PLATE 1
4 709133 TERMINAL,RING 2
5 683870 BREAKER 1P 15A 277VAC 4
6 684640 RECEPTACLE 20A 120V DUPLEX W/GFI 1
7 683970 BREAKER MINI 1P 20A 1
8 684450 RECEPTACLE 30A 240V 1
9 C54100600 NUT, NYLOCK, 8-32 ZINC 5
10 684380 SWITCH, IGNITION LEVER OPERATED 1
10A included with item 10
11 116765 WIRE HARNESS,DC ENGINE 1
12 680030 CONNECTOR,2 SCREW,3/4" 1
13 685672 CONNECTOR 9P,FEMALE 1
14 685674 SOCKETS, FEMALE 9
15 800003 CONNECTOR WITH WIRES (includes 13 and 14) 1
16 686220 CONNECTOR,2 SCREW,1.25 1
16A included with item 16
17 709032 TERMINAL,CLOSED END 2
18 680060 WRAP CAP 1
19 680290 CRIMP SLEEVE 1
20 116770 WIRE HARNESS 1
21 680250 LOCKNUT, CONDUIT 3/4" 1
22 663890 CORD SET FEMALE 6FT 5P 4
23 186542 CONTROL BOX,REAR PANEL 1
24 186540 CONTROL BOX BODY 1
25 260361 HOURMETER, DIGITAL 1
26 853289 DECAL: AL/RL CONTROL BOX DC "ENGINE CONTROLS" 1
27 186544 CONTROL BOX,FRONT PANEL 1
28 996340 SCREW,#10-16X3/4 PH ZP 12
29 995300 SCREW,#6-32X1/4 PAN HD 12
30 994420 WASHER,LOCK,#6 12
31 R660010 SWITCH PUSH-BUTTON 1
31A included with item 31
32 682715 LIGHT INDICATOR 12V RED 1
33 186543 CONTROL BOX,TOP PANEL 1
34 R661490 RELAY 12V DC 30A 1
35 186548 BRACKET, E-BOX HANGER 2
36 993310 NUTSERT,1/4-20UNC 8
37 116820 WIRING HARNESS, FROM ENGINE 1
37A 800004 KUBOTA SOLENOID PIGTAIL 1
38 116805 COMPLETE ELECTRICAL CONTROL BOX, includes 1-36 1
To Next Page
