November 2006
Part No. 833002 Rev A AL4000 Light Tower 81
ITEM # PART # DESCRIPTION QTY.
1 663850 CORD SET MALE 5FT. 3P 1
2 709034 TERMINAL STRIP, 2P 2
3 833567 CASTING FOR NEW FIXTURE 1
4 995970 WASHER LOCK STAR 1/2 2
5 991650 WASHER LOCK 1/2 2
6 990810 SCREW 1/2-13NCX1-1/2 HHC GR 2 ZP 2
7 833566 TRUNION 1
8 833573 T-HANDLE 1
9 981640 SCREW 1/2-13NCX1-1/4 HHC GRADE 5 1
10 833569 GASKET FOR REFLECTOR 1
11 833564 SOCKET BASE-MOGUL 1
12 833585 LABEL, FIXTURE CSA APPROVED 1
13 833568 REFLECTOR 1
14 833570 RING,REINFORCING FOR REFLECTOR 1
15 990675 RIVET POP 1/8X.390 GR-1/4-5/16 2
16 833524 LENS W/ GASKET 1
17 833543 CLAMP;LENS TO REFLECTOR 1
18 833574 SCREW,8-32X1" HH SLOT 1
19 833581 WASHER, FIBER FOR BAND 1
20 833578 NUTSERT FOR BAND,8-32 X 1/4 1
21 NPN included with item 17 1
22 160071 LAMP MH 1000W 1
23 833571 SCREW,10-24X5/8 4
24 160140 LAMP HPS 1000W 1
25 833565 SCREW 8-32X3/8 PH 2
26 833563 SOCKET BRACKET 1
27 833577 SCREW,8-32X5/8 2
28 833584 LABEL,105C CORD RATING 1
29 833583 LABEL,WET LOCATION 1
30 833582 FIBERGLASS WIRE SLEEVE 1
31 683950 GASKET 1/2 S/R CONN 1
32 680020 LOCKNUT CONDUIT 1/2 1
33 682470 CONNECTOR STRAINRELIEF 1
34 120102 LAMP SUPPORT 2
35 C41100720 COMPLETE FIXTURE ASSEMBLY 1
(Includes items 1-34)
