16
Service
Training
Relays
1 Headlight - Main
2 Headlight - Dip
3 Sidelights / Number Plate / Illum Inst Pack
4 Brake Lights
5 Hazard enable
6 Indicator/hazard enable
7 Front Wiper
8 Rear Wiper
9 Front Washer
10 Rear Washer
11 Front Horn / Rear Horn
12 Indicators flasher unit
13 Front Worklights
14 Rear Worklights
15 Rotating Beacon
16 Float enable relay
17 Clamp
18 Digger Quick Attach
19 RTD
20 Unloader
21 Loader Quick Attach
22 Ride Control Solenoids
23 Gearbox - Forward
24 Gearbox - Reverse
25 4WD Switch
26 Hose Burst
Main Fuses Rating
1 Alternator 125
2 Cab (Ignition) 80
3 Cab (Battery) 80
4 Ignition Feed (Thermostart) 20
5 Starter Relay and Solenoid 40
Fuses Rating
1 Headlight - Main – Left 7.5
2 Headlight - Main – Right 7.5
3 Headlight - Dip – Left 7.5
4 Headlight - Dip – Right 7.5
5 Sidelights - Left/Number Plate 3
6 Sidelights – Right 3
7 Indicators 5
8 Hazard 10
9 Worklights – Front 15
10 Worklights – Front 15
11 Worklights – Rear 15
12 Worklights – Rear 15
13 Rotating Beacon 15
14 Brake Light – Left 3
15 Brake Light – Right 3
16 Instrument Pack Illumination 3
17 Difflock / 4WD 7.5
18 Clamp / Q/A Digger / Q/A Loader 7.5
19 RTD / Unloader Valve 5
20 Fr Wiper / Rear Wiper /
Fr Wash / Rear Wash 15
21 Interior Light / Radio 7.5
22 Front Horn / Rear Horn 10
23 Ride Control Solenoids 10
24 Gearbox - Forward/Reverse 5
25 Fuel Solenoid / Fuel Enrich 7.5
26 HMU 15
27 Air Conditioning Switch 7.5
28 Cigar Lighter 15
29 Heater 25
30 Switch Pack & I Pack – Ignition 10
31 Switch Pack & I Pack – Battery 3
32 Battery Relay Coils 5
33 Ignition Relay Coils 5
