Service
Training
CARRARO (2 WHEEL) STEER SERVICE BRAKES
47
Bleeding Brakes One at a Time (2 Man Job)
1.Park on flat level ground & apply park brake. Fully dump loader bucket & lower it to ground. Stop the engine.
2.The bleeder screws are on top of the rear axle near the differential housing.
3.Constantly fill reservoir to ensure air does not enter system.
One person operates the brake pedal while the other is under the machine to open & close bleed screws.
4.Using a tube with a check valve or a tube, one end on the bleed screw and the other submersed in brake fluid.
5.Pump the RH brake pedal until air stops coming out of the tube. Hold the pedal down while closing the
bleed screw.
6.Repeat step 3 to 5 for the LH Brake.
7.Join Brake Pedals and apply the brakes. The Brake Pedal should be firm and not go to the floor.
8.Top off the Reservoir as required then road test each brake seperate and together.
