148 GTH 4016 R - GTH 4018 R - GTH-5021 R Part No. 57.0009.0607
Second Edition - First Printing
Test
Overload Test Procedure
Telehandler coupled to attachments with fixed centre of load (Forks, Bucket, Clamps):
1,33 x Q
Q = Nominal Rated Load Capacity
Telehandler coupled to attachments with oscillating centre of load (Hook, Jib, Hoist):
1,33 x Q + 0,1 x Fb on tires
1,25 x Q + 0,1 x Fb on outriggers
Q = Nominal Rated Load Capacity
Fb = Boom weight reduced (i.e. equal overturning moment) at boom tip.
