Copyright © 2015 by Terex Corporation
Second Edition: First Printing, May 2015
Genie is a registered trademark of Terex South
Dakota, Inc. in the U.S.A. and many other
countries. “GTH” is a trademark of Terex South
Dakota, Inc.
May 2015
GTH-4016 R - 4018 R - 5021 R Part No. 57.0009.0607
Second Edition - First Printing
TEREX Global GmbH
Bleicheplatz 2
8200 Schaffhausen
Switzerland
Technical Assistance Service
Telephone: +39 075 9418129
+39 075 9418175
e-mail: UMB.Service@terex.com
Contents
Introduction .......................................................... 1
Symbol and Hazard Pictorials Definitions............ 5
General Safety..................................................... 7
Work Area Safety ............................................... 15
Safety Precautions ............................................ 23
Legend............................................................... 26
Controls ............................................................. 28
Inspections ........................................................ 36
Operating Instructions ....................................... 54
Parking and Storage .......................................... 74
Transport and Lifting Instructions ...................... 76
Maintenance ...................................................... 81
Attachments....................................................... 91
Specifications .................................................. 100
Load Charts ..................................................... 103
Test.................................................................. 148
EC Declaration of Conformity .......................... 149
