Terex Genie GTH-4016 R User Manual

May 2015
46 GTH 4016 R - GTH 4018 R - GTH-5021 R Part No. 57.0009.0607
Second Edition - First Printing
Inspections
Part No. Decal Description Qty
215645
Danger – Explosion/Burn Hazard,
Fueling
1
215646 Warning – Electrocution Hazard 3
215648 Danger - No Riders 1
237720
Warning – Crush Hazard, Moving
Machine
2
237721 Warning – Dress seat Belt 1
237726 Warning – Burn Hazard 1
09.4616.0040 Label – 4000 kg 1
09.4618.0920 Warning – Engine Compartment 1
09.4618.0922 Warning – Crush Hazard 2
09.4618.0923 Warning – Burn Hazard, Hot Parts 3
09.4618.0924 Warning – Explosion Burn Hazard 1
09.4618.0986 Warning - Crush Hazard Belt Fun cooler 1
09.4618.1051 Label – Engine Compartment Opening 2
09.4618.1120 Warning – Crush Hazard, Moving Parts 2
09.4618.1895 Label - Test Ports 1
09.4618.1263 Label - Slewing Upper Structure Mark 1
09.4618.1264 Label - Chassis Mark 1
09.4618.1375 Warning - Tip Over, Respect Capacity 1
09.4618.1398 Label - Attachment Locking Pin 1
09.4618.1399 Label - Door Unlock 1
09.4618.1418 Label - Emergency Exit 1
09.4618.1419 Label - Naturelle Hydraulic Oil 1
09.4618.1423 Danger – Explosion/Burn Hazard 1
09.4618.1456 Label - Left Control Lever 1
09.4618.1457
Label - Right Control Lever with Left
Control Lever
1
Part No. Decal Description Qty
09.4618.1458 Warning - Tip Over, Respect Capacity 2
09.4618.1936 Cosmetic - Genie GTH-4018 R 1
09.4618.1839 Cosmetic - Genie GTH-4018 R 1
09.4618.0243 Cosmetic - Genie 1
09.4618.1693 Cosmetic - Genie 1
09.4618.1918 Cosmetic - Genie 1
09.4618.1917 Cosmetic - Genie 1
09.4618.1645 Label - Load Limiting System Disabling 1
09.4618.1670 Label - Hydraulic Oil 2
09.4618.1671 Label - ULSD Fuel (only for EU Market) 1
28159 Label - Diesel (for NOT EU Market) 1
09.4618.1673 Warning - Crush Hazard, Outriggers 8
09.4618.1674 Warning - Crush Hazard, Safety Collar 2
09.4618.1946 Warning - Tip Over, Outriggers Pmax 4
09.4618.1682 Label - Tyre Pressure 5.5 bar 4
09.4618.1949 Label - Anchoring & Lifting 1
09.4618.1678 Label - Cut-off Switch 1
09.4618.1679 Warning - 7 decals 1
09.4618.1694 Label - Right Control Lever 1
09.4618.1695
Label - Right Control Lever with Lock/
Unlock
1
09.4618.1713 Warning - Burn Hazard 1
09.4618.1740 Label - Mainvalve Manual Use 1
09.4618.1769 Label - Lock 1
09.4618.1770 Label - Unlock 1
09.4618.1771
Label - Sound Level 102 dB (only stage
3B)
1
09.4618.1819 Label - TP1 Testing Port 1
09.4618.1820 Label - TP5 Testing Port 1
09.4618.1821 Label - TP8 Testing Port 1
09.4618.1829 Label - Eco logo Decal (only Stage 3B) 3
Inspection for GTH 4018 R Decals
Use the pictures on the next page to verify that all
decals are legible and in place.
Below is a numerical list with quantities and
descriptions.
