Terex Genie GTH-4016 R User Manual

May 2015Second Edition - First Printing
Part No. 57.0009.0607 GTH 4016 R - GTH 4018 R - GTH-5021 R 51
Part No. Decal Description Qty
09.4618.1642 Label - Load Chart Fork Front 1
09.4618.1644 Label - Load Chart Fork Side 1
09.4618.1643
Label - Load Chart Fork 360° on
Outriggers
1
09.4618.1696
Label - Load Chart Hook 360° on
Outriggers
1
09.4618.1697 Label - Load Chart Hook Front 1
09.4618.1698 Label - Load Chart Hook Side 1
09.4618.1699
Label - Load Chart 900 kg Jib 360° on
Outriggers
1
09.4618.1700 Label - Load Chart 900 kg Jib Front 1
09.4618.1701 Label - Load Chart 900 kg Jib Side 1
09.4618.1702
Label - Load Chart 2000 kg Jib 360° on
Outriggers
1
09.4618.1703 Label - Load Chart 2000 kg Jib Front 1
09.4618.1704 Label - Load Chart 2000 kg Jib Side 1
09.4618.1705
Label - Load Chart 4000 kg Winch 360°
on Outriggers
1
09.4618.1706 Label - Load Chart 4000 kg Winch Front 1
09.4618.1707 Label - Load Chart 4000 kg Winch Side 1
09.4618.1891
Label - Load Chart 5000 kg Winch 360°
on Outriggers
1
09.4618.1889 Label - Load Chart 5000 kg Winch Front 1
09.4618.1890 Label - Load Chart 5000 kg Winch Side 1
09.4618.1708
Label - Load Chart Bucket 360° on
Outriggers
1
09.4618.1709 Label - Load Chart Bucket Front 1
09.4618.1710 Label - Load Chart Bucket Side 1
09.4618.1711
Label - Load Chart 3P700 REM4400
Manplatform on Outriggers (for NOT EU
Market)
1
Inspections
Part No. Decal Description Qty
09.4618.1712
Label - Load Chart 2P300 F
Manplatform on Outriggers (for NOT EU
Market)
1
09.4618.1827 Label - Do not use high pressure 2
09.4618.1884
Label - Load Chart Fork Side Shift and
positioner Front wheels
1
09.4618.1885
Label - Load Chart Fork Side Shift and
positioner Side wheels
1
09.4618.1886
Label - Load Chart Fork Side Shift and
positioner Outriggers
1
