May 2015
56 GTH 4016 R - GTH 4018 R - GTH-5021 R Part No. 57.0009.0607
Second Edition - First Printing
Adjusting the Rear View Mirrors
The machine is fitted with three rear view mirrors.
To adjust their positions, manually rotate them to
the position(s) which provides optimal visibility.
1. Allows checking the area behind the machine
and on the right-hand side.
2. Allows checking the area behind the machine
and on the left-hand side.
3. Allows checking the area behind the machine.
Operating Instructions
Fastening the Seat Belts
A
B C
Sit correctly in the driving seat; then:
• The seat belt is equipped with a reel retractor.
• To fasten the belt, pull tab 1 and push it into
buckle 2.
• To release the belt, push button 3 and remove
the tab from the buckle.
• Make sure that the buckle is correctly located
at the hip point and not on the stomach.
