Terex Genie GTH-4016 R User Manual

May 2015
92 GTH 4016 R - GTH 4018 R - GTH-5021 R Part No. 57.0009.0607
Second Edition - First Printing
Genie GTH 5021 R Approved
Attachments List:
• Floating Forks
(part number 55.0750.0082)
• Forks Side Shift and positioner
(part number 59.0601.5027)
• FEM3 Forks with Hydraulic SIDE-SHIFT +/-
100mm
(part number 59.0601.5012)
• UK Floating Forks L1200mm sect.100x65mm
(part number 55.0750.0083)
• Loading shovel 800 Lt
(part number 59.0201.9008)
• Concrete bucket 500 Lt manual discharge
(part number 59.0401.2012)
• Concrete bucket 500 Lt hydraulic discharge
(part number 59.0401.2013)
• Concrete bucket 800 Lt manual discharge
(part number 59.0401.2014)
• Concrete bucket 800 Lt hydraulic discharge
(part number 59.0401.2015)
• Concrete mixing bucket 500 Lt full hydraulic
(part number 59.0401.2016)
• Brick-holder basket
(part number 59.0401.2017)
• Fixed hook on plate
(part number 59.0700.9007)
• Mechanical jib 2m length/ 2000kg capacity
(part number 59.0802.3016)
• Mechanical jib 4m length/900kg capacity
(part number 59.0802.3017)
• Hydraulic jib, 4m length/900kg capacity
(part number 59.0802.3018)
• Hydraulic winch 4000 kg
(part number 59.0901.9005)
• Hydraulic winch 5000 kg
(part number 59.0901.9008)
Attachments
• Fixed man-platform: 2P/300-F
(part number 59.1111.6013)
• Rotating and extendable man-platform:
3P/700-REM 4400 +/- 90°
(part number 59.1111.6014)

Terex Genie GTH-4016 R Specifications

General

Brand	Terex
Model	Genie GTH-4016 R
Category	Lifting Systems
Language	English
