Operating Instructions Wheel Loader TL120
Care and Maintenance 7
7.8.11 Replacing the breather
• Unscrew the oil dipstick (59/1).
• Remove the breather (59/2) and dispose of
according to regulations.
• Clean the screen (59/4) and check for damage;
replace if required.
• Screw in new breather (59/2) with O-ring (59/3)
and tighten by hand.
• Screw back in the oil dipstick.
Fig. 59 Replacing the breather
L834-054
1
3
2
4
Attention
• The breather must also be replaced if it is
dirty, for example due to hydraulic oil
vapor.
