INSTRUCTIONS DE REPARATION
REPARATURANLEITUNG
REPAIR INSTRUCTIONS
DOCUMENT No: 334.80051 V03
DATE :15/08/2002
Modified cards Old Ident New Ident.
For M-H after 7E
Kit with parts for the
adaptation of new
components on a old
Micro-Hite version
Supply Board 034489 034489
038321
consisting of:
1x 034489
4x Block 037874
3x Block 034491
1x Plate 035219
7 x Scew 024076
Sensor Module 036602 038320
038320
consisting of:
1x Print 037878
1x Circuit flex 037877
1x Square 038073
1x Contact 014519
1x Plate 034791
Probing Board 034520 037903
037903 + 034358
Testing Board 629.9159 629.9159 V1
New adjusting
procedure is included
with the new card
.
Resistive Track 034571 034571
038319
Nota : if you replace the Sensor Modul 036602 by a new 038320 you must change also the Probing Board 03420 with
the new 037903+034358
