10 ER3000 User Manual
3. ER3000 PART NUMBERING SYSTEM
Standard features:
RS485 communications included.
1/8” inlet and exhaust ports, 1/4” controlled output port.
Maximum inlet pressure = 120 psig.
0 to 100 psig internal sensor.
Windows/DOS software package included.
24 VDC power required.
As the table below indicates, other sensor ranges are available. Please consult
the factory for special modifications or requirements.
ER3 XX
X X X - X
Base Style
00…Standard
02…Integrated with
26-1000 and 269-529
04…OEM style (no
cover)
10…Integrated with
44-4000
11…Integrated with
44-5200
Internal Sensor Configuration
0…0-100 psig, 0.1% accuracy
2…0-50 psia, 0.1% accuracy
3…0-150 psia, 0.1% accuracy
4 0-5 psig, 0.25% accuracy
Board Configuration
S…Standard
(setpoint/feedback)
F…2 extra analog
inputs/outputs
E…Explosion proof
G…Combines F & E
M…KEMA explosion proof
Current/Voltage
I…4-20 mA/1-5 VDC
V…0-10 VDC
Cv
Configuration
1…Standard,
Cv=0.01
2…Low flow
(Cv=0.001)
4…High flow
(Cv=0.1)
To Next Page
