3. Installation
3.1 Unpacking Inspection
1. Open the packing box of UPS and take them out, visually examine the units for transit damage.
2. Check against the accessory lists that the accessories of the UPS are present.
(Refer to Table 3-1)
3. If the UPS arrives damaged, or there is any missing accessory, please contact the distributor
immediately.
Table 3-1 Accessory list of UPS
Model Accessory Quantity Unit
standard
RS232 Communication Line 1 Pcs
User manual 1 Pcs
A Winpower software CD 1 Pcs
long backup time
RS232 Communication Line 1 Pcs
User manual 1 Pcs
A Winpower software CD 1 Pcs
External Battery Cable 1 Pcs
3.2 Installation Notes
1. When locating the UPS, make sure there is no hazardous objects around the UPS, and that the
installation environment meets the specifications.
2. The UPS should not be titled. The air inlet port at the front panel and the fan outlet port on the
rear panel should not be blocked so as to ensure good ventilation.
3. In case if the UPS is unpacked, installed and used at very low temperatures, condensations of
water drops may appear. It is necessary to wait until the UPS fully dried inside out before
proceeding to installation and use. Otherwise, they may be a risk of electric shock.
4. Place the UPS near the utility power source outlet which supplies power to the UPS. In any
emergency, switch off the main input socket, cut off the battery voltage input. All power sockets
must be connected with ground protection.
