25
Model
NEOLINE
1000
NEOLINE
1000XL
NEOLINE
2000
NEOLINE
2000XL
NEOLINE
3000
NEOLINE
3000XL
Rating
1kVA/800W
2kVA/1600W
3kVA/2400W
Input
Input system Single phase & earth ground
Rated voltage 220VAC
Voltage range
115VAC～300VAC
Frequency 50Hz
Power factor 0.99
Voltage range of
bypass
80VAC* (1±5%) ～285VAC* (1±5%)
Output
Output system Single phase & earth ground
Rated voltage 220VAC
Power factor 0.8
Voltage precision ±2%
Output
frequen
cy
Normal
mode
1.The output frequency synchronizes with the input frequency when the
input frequency is in the range of 46 Hz～54 Hz
2.The output frequency is 50Hz when the input frequency is not in the range
of 46 Hz～54 Hz
Battery
mode
50
±
0.2 Hz
Inverter overload
capacity（Utility
power，25
℃
）
108%±5%<Load≤150%±5% 47s～25s
150%±5%< Load <200%±5% 25s～300ms
Load ≥200%±5% 300ms
Transfer time
0ms （Normal mode
⇌
Battery mode）
<4ms（Normal mode
⇌
Bypass mode）
Crest factor 3:1 (max)
Batter
y
Batteries voltage 36VDC 72VDC 96VDC
Battery
capacity*Quantity
12VDC*3 12VDC*6 12VDC*8
Backup Time
（25
℃
）
Full load ≥4min (Standard)
Battery charge
time
Charger to 90% battery capacity in 5 hours（Standard）
Dependent on the capacity of external batteries（Long backup time）
7.2 Mechanical
Model W*H*D(mm) Weight(kg)
NEOLINE 1000
145×220×355 12 kg
NEOLINE 1000XL
145×220×355 6.5 kg
NEOLINE 2000
190×318×383 23 kg
