6. Specifications
Tower Models
MODEL
1K 2B
1K 3B
1.5K
2K 4B
2K 6B
3K
CAPACITY*
1000VA/1000W
1500VA/1500W
2000VA/2000W
3000VA / 3000W
INPUT
Voltage
Range
Low Line Transfer
160VAC/140VAC/120VAC/110VAC ± 5 % or 80VAC/70VAC/60VAC/55VAC ± 5 %
( based on load percentage 100% - 80 % / 80 % - 70 % / 70 - 60 % / 60 % - 0)
Low Line
Comeback
175VAC/155VAC/135VAC/125VAC ± 5 % or 87VAC/77VAC/67VAC/62VAC ± 5 %
High Line Transfer
300 VAC ± 5 % or 150 VAC ± 5 %
High Line
Comeback
290 VAC ± 5 % or 145 VAC ± 5 %
Frequency Range
40Hz ~ 70 Hz
Phase
Single phase with ground
Power Factor
≧ 0.99 @ full load
THDi
≦ 5% @ 205-245VAC or 100~130VAC
THDU < 1.6% @ input and full linear load condition
OUTPUT
Output voltage
200/208/220/230/240VAC or 100/110/115/120/127 VAC
AC Voltage Regulation
± 1% (Batt. Mode)
Frequency Range
(Synchronized Range)
47 ~ 53 Hz or 57 ~ 63 Hz
Frequency Range
50 Hz ± 0.1 Hz or 60Hz ± 0.1 Hz (Batt. Mode)
Current Crest Ratio
3:1
Harmonic Distortion
≦ 2 % THD (Linear Load) ; 4 % THD (Non-linear Load)
Transfer
Time
AC Mode to Batt.
Mode
Zero
Inverter to Bypass
< 4 ms
Waveform (Batt. Mode)
Pure Sinewave
EFFICIENCY
AC Mode
≧89% @ full charged battery
≧91% @ full charged battery
ECO Mode
≧96% @ full charged battery
Battery Mode
≧88%
≧90%
BATTERY
Battery Type
12V/9AH
12V/7AH
12V/9AH
12V/9AH
12V/7AH
12V/9AH
Numbers
2
3
3
4
6
6
Recharge Time
3 hours recover to 95% capacity for internal battery@ 2A charging current
Charging Current
100/110/115/120 /127 VAC models: default 2A, max.
8A adjustable
200/208/220/230/240 VAC models: default 2A, max.
12A adjustable
Default: 2A, Max: 8A adjustable
Charging Voltage
27.4 VDC
± 1%
41.0 VDC
± 1%
41.0 VDC ± 1%
54.7 VDC
± 1%
82.1 VDC
±1%
82.1 VDC ±1%
PHYSICAL
Dimension, D X W X H (mm)
397 X 145 X 220
421 X 190 X 318
Net Weight
(kgs)
With battery
11.7
13.0
14.6
20.3
23.2
28.0
Without battery
6.6
6.6
7
9.9
9.9
12.3
ENVIRONMENT
Operation Humidity
20-95 % RH @ 0- 40°C (non-condensing)
Noise Level
Less than 50dBA @ 1 Meter (With fan speed control)
MANAGEMENT
Smart RS-232 or USB
Supports Windows® 2000/2003/XP/Vista/2008/7/8/10, Linux, Unix and MAC
Optional SNMP
Power management from SNMP manager and web browser
* Derate capacity to 80% of capacity in Frequency converter mode and to 80% when the output voltage is adjusted to 100VAC, 200VAC or
208VAC. For 100/110/115/120/127VAC system, the output power ratings are different based on different input voltage. Please check output
power rating table for the details.
** Product specifications are subject to change without further notice.
MODEL Prime Plus 1101RT Prime Plus 1102RT Prime Plus 1103RT
TESCOM MODEL UPS.0538 UPS.0539 UPS.0509
PHASE Single phase with ground
CAPACITY 1000 VA / 1000 W 2000 VA / 2000 W 3000 VA / 3000 W
INPUT
Nominal Voltage 200/208/220/230/240 VAC
Voltage Range
110-300 VAC ± 5% @ 50% load
160-300 VAC ± 5% @ 100% load
Frequency Range 40Hz ~ 70Hz
Harmonic Distortion(THDi) ≤ 5% @ nominal input voltage
Power Factor ≥ 0.99 @ nominal voltage (100% load)
OUTPUT
Output Voltage 200*/208*/220/230/240 VAC
AC Voltage Regulation (Batt. Mode) ± 1%
Frequency Range (Synchronized Range) 57 ~ 63 Hz or 47 ~ 53 Hz or
Frequency Range (Batt. Mode) 50 Hz ± 0.1Hz or 60Hz ± 0.1Hz
Current Crest Ratio 3:1 (max.)
Harmonic Distortion ≤ 2 % THD (Linear Load); ≤ 4 % THD (Non-linear load)
Transfer
Time
AC mode to Battery mode Zero
Inverter to Bypass 4 ms (Typical)
Waveform (Batt. Mode) Pure Sinewave
EFFICIENCY
AC Mode ≥ 89% @ full charged battery ≥ 91% @ full charged battery
ECO Mode ≥ 96% @ full charged battery
Battery Mode ≥ 88% ≥ 90%
BATTERY
Battery Type 12 V / 9 AH 12 V / 9 AH 12 V / 9 AH
Numbers 2 4 6
Typical Recharge Time 3 hours recover to 95% capacity for internal battery@ 2A charging current
Charging Current
200/208/220/230/240 VAC models: default
2A, max. 12A adjustable
Default: 2A, Max: 8A adjustable
Charging Voltage 27.4 VDC ± 1% 54.8 VDC ±1% 82.1 VDC ±1%
PHYSICAL
Dimension, D x W x H (mm) 410 x 438 x 88 510 x 438 x 88 630 x 438 x 88
Net Weight (without battery) (kgs) 6,6 9,4 12,4
Net Weight (w/built-int battery) (kgs) 11,6 19,5 27,5
ENVIRONMENT
Humidity 20-90 % RH @ 0- 40°C (non-condensing)
Noise Level Less than 50dBA @ 1 Meter
Altitude 10% de-rating for over 1000m (The altitude should not exceed 3000m)
MANAGEMENT
Smart RS-232/USB Supports Windows® 2000/2003/XP/Vista/2008/7/8, Linux and MAC
Optional SNMP Power management from SNMP manager and web browser
STANDARD
EMC/safety EMC EN62040-2 C2 for CE models
*Derate capacity to 80% when the output voltage is adjusted to 200VAC/208VAC.
Product specications are subject to change without further notice
