Tescom T-340P - Page 10

7
Parallel System
Data Socket
(DB25 Female)
(optional)
RS232
Communication
Port
(DB9 Female)
Parallel System
Analog Signals
Socket
(DB15 Female)
(optional)
Dry Relay Output Contacts
Battery Circuit
Breaker Input
Emergency
Stop
Line Failure
Relay
Battery Low
Relay
By-Pass
Relay
Figure 1.3.a
40-60 kVA Power Switch Locations
Static By-Pass
Control Switch
(optional)
RS232 – SNMP
Communication
Select Switch
SNMP Socket
(optional)
