Tescom T-340P - Safety Earth; Cable Connections

28
UPS
RATING
(kVA)
NOMINAL CURRENT : Amps / Recommended Cable Size (mm
2
)
BUS BAR CONNECTION
STUD SIZE
Input Mains
With full battery Recharge
Bypass / output
At full load
Battery
at min.
Battery
Voltage
Input/Output
Cable
Terminations
U-V-W-N
Battery
Terminations
+ & -
380V 400V 415V 380V 400V 415V
A / mm
2
A / mm
2
A / mm
2
A / mm
2
A / mm
2
A / mm
2
A / mm
2
40
85A / 25 78A / 25 73A / 25 61A / 16 58A / 16 56A / 16 110A / 35
M6 M8
60
128A / 35 117A / 35 109A / 35 91A / 25 87A / 25 84A / 25 163A / 50
M6 M8
80
168A / 50 160A / 50 154A / 50 121A / 35 115A / 35 111A / 35 220A / 70
M6 M8
NOTES: The neutral conductor should be sized for 1,5 times the output/bypass phase current. The Earth
conductor should be sized at 2 times the output/bypass conductor (this is dependent on the fault
rating, cable lengths, type of protection etc.) These recommendations are for guideline purposes only
and are superceded by local regulations and codes of practice.
Safety Earth
The safety earth cable must be connected to the earth BUS BAR and bonded to each cabinets in the system
and also the earthing and neutral bonding arrangements must be in accordance with the local laws.
ATTENTION!!! Failure to follow adequate earthing procedures can result in electric shock hazard to
personnel, or the risk of fire.
Cable Connections
ATTENTION!!! All the cable connections of the ups must be done by the authorized service personnel.
Once the equipment has been finally positioned and secured, connect the power cables as described in the
following procedure:
