VIII. ECONO OPERATING MODE
ECONO OPERATING MODE :
UPS operating mode can be selected on front panel. Operating mode can be selected in user settings main
menu (Settings or Options menu ) on front panel depending on the additional optional features of the UPS.
Hardware options according to operating modes are shown in the following table.*
Operating Mode Necessary Hardware
MODE:ONLINE All the Hardwares are installed as standard
MODE:PARALLEL Paralleling hardware required
MODE:REDUNDANT Paralleling hardware required
MODE:ECONO Econo mode hardware required
In order to use the ECONO mode, the necessary equipment must be installed in the factory when ordering
the product, or contact our authorized service to add ( if possible) this function.
*Operating mode will not be activated , if the Enter button is not pressed for 2-3 seconds after operating mode selection and then UPS is
not shutdown and restarted.
ECONO operating
UPS systems typically have an internal bypass to allow the equipment to seamlessly transfer the critical
loads to the utility or internal generation, allowing the UPS to be de-energized during service without
dropping the load.If ECONO mode is selected, the UPS supplies the load via bypass if the bypass input
supply power is available during normal operation. At a power failure, the UPS can return to normal mode
and provide conditional power to the load very fast. This mode is designed for non-critical loads. In other
words, ONLINE mode must be used for critical loads that are not susceptible to power loss for very short
time.
