8. Supported Signal Modes
A. VGA Mode
Resolution Horizontal Frequency (Khz) Vertical Frequency (Hz)
640 x 480 31.50 60.00
800 x 600 35.16 56.25
37.90 60.00
1024 x 768 48.40 60.00
1366 x 768 47.70 60.00
1920 x 1080 67.50 60.00
Note: In order to ensure optimal quality of picture, it is suggested that the VGA
connecting cord in use is no more than 5 meters long.
B. YPbPr Mode
Resolution Horizontal Frequency (Khz) Vertical Frequency (Hz)
480i 15.734 59.94
480p (720x480) 31.468 59.94
576i 15.625 50.00
576p (720x576) 31.25 50.00
720p (1280x720) 37.50 50.00
45.00 60.00
1080i 28.13 50.00
33.75 60.00
1080P (1920x1080) 67.50 60.00
56.25 50.00
C. HDMI Mode
Resolution Horizontal Frequency (Khz) Vertical Frequency (Hz)
480p 31.468 59.94
576p 31.25 50.00
720P 45.00 60.00
1080i 33.75 60.00
1080P (1920x1080) 67.50 60.00
- When signal exceeds the allowed range, a warning message will appear on the screen.
- You can confirm the input signal format on screen.
