Testboy TV 455 - Connector Panel

®
TV 450/455 Connector panel
15
3.2 Connector panel
Figure 3.2: Connector panel
Legend:
1 Test connector Measuring inputs / outputs
2 Protection cover
3 Charger socket
4 USB connector Communication with PC USB (1.1) port.
5 PS/2 connector
Communication with PC serial port and connection to optional
measuring adapters.
Warnings!
 Maximum allowed voltage between any test terminal and ground is 600 V!
 Maximum allowed voltage between test terminals is 600 V!
 Maximum short-term voltage of external power supply adapter is 14 V!
