TV 450/455 Back side
16
3.3 Back side
Figure 3.3: Back side
Legend:
1 Side belt
2 Battery compartment cover
3 Fixing screw for battery compartment cover
4 Back panel information label
5 Holder for inclined position of the instrument
6 Magnet for fixing instrument close to tested item (optional)
Figure 3.4: Battery compartment
Legend:
1 Battery cells Size AA, alkaline or rechargeable NiMH / NiCd
2 Serial number label
3 Fuse M 0.315 A, 250 V
