3 Description of the instrument
10
3.3 Displays overview
Element Function
1
Icon [ ]
Displays the remaining battery capacity.
>75%
>50%
>25%
<10%
2
Icon [ ]
Bluetooth® appears when Bluetooth has been
activated on the instrument.
3
Icon [ ]
An alarm threshold is set.
4 Temperature display - selected, currently measured temperature
- Measurement parameter:
T
H2O
= evaporation temperature of water
T
amb
= ambient temperature
Δt = temperature difference between
evaporation temperature of water and ambient
temperature
- unit set (°C, °F)
5 Slave Mode Appears when the testo 552 is connected to the
testo 570 via a connecting cable and the
testo 570 is in Evacuation mode.
6 Pressure display Displays the currently measured pressure, the
measurement parameter and the unit set (mmHG,
Torr, mbar, hPa, micron, inH2O, inHg).
