TESTO 560i - Automatic Charging by Subcooling

8 Using the product
25
8.6 Automatic charging by subcooling
This function enables a refrigerant circuit to be charged via the target subcooling
value using the testo 560i scale and the testo Smart Valve in combination with
the app or testo 550s / testo 557s manifold.
For this, the current subcooling value is determined. Based on this information,
a target subcooling value can be entered. The system is filled automatically until
the target value is reached.
Displaying the target subcooling value is only possible in combination
with testo 115i smart probes.
The appropriate maximum charge value for a system must be entered
in the [Max charge] field on the manifold/app.
The appropriate subcooling target value for a system must be entered
on the manifold/app.
When using the manifold, the app is in second-screen mode. All
settings must be made on the manifold.
Based on the specified system size the algorithm creates a maximum
weight to be filled. When this maximum weight is reached, automatic
filling is paused and must be restarted. This prevents overfilling or
incorrect filling.
Before each measurement, check that the refrigerant hoses are in
flawless condition.
The system must be supervised by a competent person throughout the
entire process.
✓
testo 560i and testo Smart Valve are connected via Bluetooth to the
testo Smart App or the testo 550s / testo 557s manifold.
✓
testo 560i and testo Smart Valve are integrated into the refrigerant
circuit.
✓
Two testo 115i are attached and connected via Bluetooth to the testo
Smart App or the testo 550s / testo 557s manifold.
1
Select the required refrigerant on the manifold/app and press
[Menu/Enter] to confirm.
1.1
If necessary, zero sensor on manifold/app [P = 0].
