4 Product description
14
4 Product description
4.1. Overview
4.1.1. Product components
1 Digital imager lens for taking visual images and two
power -LEDs for illuminating the image.
2 Infrared imager lens for taking thermograms.
3 [Release lens] for releasing the lens lock.
4 Thread (1/4" - 20 UNC) for attaching a tripod (bottom of
imager). Do not use desktop tripods: danger of tipping over!
5 Laser (not available in all countries) for marking the
measurement object.
CAUTION
Laser radiation! Class 2 laser
> Do not look into the beam.
6 Focusing ring for adjusting the focus manually.
CAUTION
Auto mechanism may be damaged!
> Only turn focusing ring when auto-focus is deactivated (
).
