6 Using the product
52
Task Actions/description
Call up function.
> | | Wizards |
SiteRecognition.
- The real image is displayed and a
position frame is shown.
Once the function has been called up
via the menu (see above) and at least
one marker has be set, the function can
also be called up via the main menu
tab.
> |
.
When the imager is switched off, the
entry is removed again from the tab.
Enter measuring site
marker.
1. Position the imager so that the
marker is inside the position frame.
2. After recognition of the marker ID:
confirm transfer of measuring site
data.
6.2.5. Configuration
Country settings
Instrument language and temperature unit can be set.
Task Actions/description
Open Country settings
input screen.
> | | Configuration |
Country settings.
Set the language of the
program interface.
> Highlight the language to be used
by touching on it.
Change temperature unit.
> .
- The activated unit is shown on the
top right of the display.
Apply entries.
> .
