6 Using the product
37
Min/max/avg on area
An area mark can be shown and freely positioned. The minimum
(min), maximum (max) and average (avg) measurement value in
this area is displayed.
Task Actions/description
Show area mark.
> | .
or
>
| | Measurement |
Min/Max on Area.
Move area mark.
> Touch and drag area mark.
Joystick operation:
1. Select area mark and activate by
pressing the joystick.
2. Move area mark by moving the
joystick.
> To exit: Press joystick again and
activate Quit moving in the context
menu.
Change size of area
mark/hide area mark.
> Press again.
Alarm
The alarm function shows all image points with measurement
values that exceed the upper alarm mark or fall below the lower
alarm mark in a single colour (alarm colour). To set the alarm
colours, see Colour selection, page 45.
Task Actions/description
Open Alarm input screen.
>
| .
or
>
| | Measurement | Alarm.
Activate/deactivate Lower
alarm or Upper alarm.
> Active.
> To deactivate, touch the button
again.
