6 Using the product
45
Histogram adjustment
By adjusting the colour palette to the current temperature
distribution, histogram adjustment particularly in the case of scenes
with a large temperature scope (e.g. with high-temperature
measurements) increases the contrast.
When histogram adjustment is activated, the colours within
the scale are no longer distributed in a linear pattern
between the minimum and maximum scale value. It is
therefore difficult to draw conclusions about temperatures
from colours.
Task Actions/description
Activate/deactivate
Histogram adjustment.
>
| | Display options |
Histogram adjustment.
Colour selection
The colours used for the measurement functions Isotherm and
Alarm can be set.
Task Actions/description
Open Colour selection
input screen.
> | | Display options |
Colour selection.
Set required colour for
Isotherm, Top Alarm or
Bottom Alarm.
> .
> Activate colour to be used by
touching it.
Apply entries.
> .
