TechNIcAl dATA 13
© TESVOLT We reser ve the right to make technical changes. Version RD.TI.015.E.ENG_Installation_Manual_TS48V_v.C.01 Last revised 06/2020
TECHNICAL DATA
. TESVOLT TS V
TESVOLT BATTERY MODULE
Energy module 4.8 kWh
C-rate 1 C
Cell Lithium NMC prismatic (Samsung SDI)
Max. charging/discharging current 94 A
Cell balancing Active battery optimizer
Cycles @ 100 % DoD | 70 % EoL | 23 °C +/- 5°C 1C/1C 6,000
Cycles @ 100 % DoD | 70 % EoL | 23 °C +/- 5 °C 0.5 C/0.5C 8,000
Efficiency (battery) up to 98 %
Operating voltage 47.6 to 58.1 V
DC
Operating temperature -10 to 50 °C
Humidity 0 to 85 % (non-condensing)
Altitude of installation site < 2,000 m above sea level
Weight 36 kg
Dimensions (H x W x D) 163 x 490 x 480 mm
Certificates/standards Cell IEC62619, UL1642, UN38.3
Product CE, UN 38.3, IEC 61000-6-1/2/3/4, BattG 2006/66/EG
Guarantee 10-year performance guarantee, 5-year system guarantee
Recycling TESVOLT provides a free battery collection scheme in Germany
COMPLETE SYSTEM
Number of battery modules 2 3 4 5 6 7 8 9 10
TS 25 (2 – 5 modules)
1300 x 600 x 600 mm (H x W x D)
•
• • •
TS 40 (6 – 8 modules)
1900 x 600 x 600 mm (H x W x D)
• • •
TS 50 (9 – 10 modules)
2300 x 600 x 600 mm (H x W x D)
• •
TS Flex (energy as required) Flexibly configure your system according to your requirements.
Energy [kWh] 9.6 14.4 19.2 24.0 28.8 33.6 38.4 43.2 48.0
Capacity [Ah] 188 282 376 470 564 658 752 846 940
Maximum output power 1 C
Selfconsumption (standby) 3 watts (without battery inverter)
Weight [kg] 192 228 264 300 386 422 458 514 550
System single-phase, three-phase
Protection class IP 20 (indoor use)
