. SCOPE OF DELIVERY FOR OTHER COMPONENTS
ITEM QUAN
TITY
DESCRIPTION
10
1 Switch
11
1 or 3 SMA Sunny Island 4.4 M/6.0 H/8.0 H
12
1 SMA Sunny Home Manager 2.0
13
1 SMA Data Manager M alternative for item 12; incl. external 24 V power supply
14
1 SMA Energy Meter 2.0 alternative for item 12
15
Optional LV B01 2X bat fuse
15.1
3
L
NH1 250 A tag fuse
16
Optional LV B03 4X bat fuse
16.1
6
L
NH1 250 A tag fuse
17
Optional DC connector kit bat fuse to Sunny Island (10 m)
17.1
1
L
DC connecting cable – 10.00 m 50 mm²
17.2
6
L
50 mm² M8 ring cable lug
17.3
6
L
50 mm² M10 ring cable lug
17.4
6
L
Thin-wall heat shrink tubing, 40 mm, red
17. 5
6
L
Thin-wall heat shrink tubing, 40 mm, blue
18
Optional Cabinet connector kit – 1.20 m or 2.30 m
18.1
1
L
DC connecting cable – 1.20 m or 2.30 m 120 mm² (+, M8 ring cable lugs, with red marking on both ends)
18.2
1
L
DC connecting cable – 1.20 m or 2.30 m 120 mm² (-, M8 ring cable lugs with blue marking on both ends)
18.3
1
L
CAT 6 patch cable - 2.00 m or 3.00 m)
18.4
2
L
DIN 6921 - M8 x 20 hexagon flanged bolt
19
Optional Emergency power distribution, single-phase
20
Optional Emergency power distribution, three-phase
