18 Ts 48 V bATTeRy sTORAge sysTeM
© TESVOLT We reser ve the right to make technical changes. Version RD.TI.015.E.ENG_Installation_Manual_TS48V_v.C.01 Last revised 06/2020
. OTHER COMPONENTS
10
14 15 16
11 12 13
Switch
SMA Energy Meter 2.0
LV B01 2X bat fuse and NH1
250 A tag fuse
LV B03 4X bat fuse and NH1
250 A tag fuse
SMA Sunny Island SMA Sunny Home
Manager 2.0
SMA Data Manager M incl.
external 24V power supply
unit
18 19 20
18.1
18.2
18.3
18.4
Cabinet connector kit
1.20 m or 2.30 m
Single-phase emergency
power distribution
Three-phase emergency
power distribution
17
17.1
17.4 17.5
17.3
17.216.115.1
DC connector kit bat fuse to
Sunny Island (10 m)
17
17.1
