TesVOlT bATTeRy MONITORINg sOfTwARe – bATMON
© TESVOLT We reser ve the right to make technical changes. Version RD.TI.015.E.ENG_Installation_Manual_TS48V_v.C.01 Last revised 06/2020
. MENU STRUCTURE
The battery parameters are password protected. Since these parameters directly affect the battery,
they may only be configured by certified qualified specialists. You can obtain the password by directly
requesting it from Service staff at TESVOLT GmbH.
BATTERY CELLS EVENTS PARAMETERS SYSTEM SELECTION
Charging/discharging
power
Cell voltage Event logbook Battery parameters Current errors Master
Battery voltage Cell temperature Clear events Load default BatMon version Slave
Charging/discharging
current
SoC (cell) Save events (as PDF) Save default Expert level
Battery temperature SoH (cell) Reset APU Start logging
Balancing mode Module voltage Firmware update
Charging cycle (kWh) Charging/discharging
power
Communication port
Discharging cycle (kWh) ABO temperature
SoC (state of charge)
SoH (state of health)
Warning – time Displayed Expert settings Functions
APU temperature data Only with password
. THE MOST IMPORTANT CELL PARAMETERS
SoC – state of charge
This value indicates the percentage that the battery has been charged to. 100% refers to a fully
charged battery. The APU LV can use the parameters to determine the state of charge of a single cell
or battery module, and to stop the charging process if necessary. This prevents overcharging. The
software also has the same function for monitoring the discharge process to prevent unnecessary cell
charging. Battery limit states define the points at which the system stops charging and discharging.
SoH – state of health
This value indicates a cell’s health. Precise monitoring allows the system to detect performance differ-
ences between individual cells and thus detect damaged/defective cells.
