Table 5-1. BQ76942 Circuit Module Bill of Materials (continued)
Designator Quantity Value Description Package Reference Part Number Manufacturer
C56 1 2200pF CAP, CERM, 2200 pF, 10
V, +/- 10%, X7R, 0402
402 8.85012E+11 Wurth Elektronik
D1, D2, D10 3 100V Diode, Schottky, 100 V,
0.15 A, SOD-123
SOD-123 BAT46W-7-F Diodes Inc.
D3 1 Red LED, Red, SMD LED_0603 150060RS75000 Wurth Elektronik
D4, D5, D6 3 16V Diode, Zener, 16 V, 500
mW, SOD-123
SOD-123 MMSZ5246B-7-F Diodes Inc.
D7 1 40V Diode, Schottky, 40 V, 0.2
A, SOT-323
SOT-323 BAS40W-7-F Diodes Inc.
D8 1 100V Diode, Ultrafast, 100 V,
0.15 A, SOD-123
SOD-123 1N4148W-7-F Diodes Inc.
D9 1 10V Diode, Zener, 10 V, 500
mW, SOD-123
SOD-123 MMSZ4697T1G ON Semiconductor
D14, D15, D16 3 Green LED, Green, SMD LED_0603 150060VS75000 Wurth Elektronik
H1, H2, H3, H4 4 Bumpon, Hemisphere,
0.44 X 0.20, Clear
Transparent Bumpon SJ-5303 (CLEAR) 3M
J1 1 TERM BLOCK 3.5MM
VERT 5POS PCB
HDR5 OSTTE050161 On Shore Technology
J2, J18 2 Header, 2.54mm, 5x1,
Tin, TH
Header, 2.54mm, 5x1, TH PEC05SAAN Sullins Connector
Solutions
J3 1 TERM BLOCK 3.5MM
VERT 6POS PCB
HDR6 OSTTE060161 On Shore Technology
J4 1 Header, 100mil, 6x1, Tin,
TH
TH, 6-Leads, Body
608x100mil, Pitch 100mil
PEC06SAAN Sullins Connector
Solutions
J5, J6, J8, J10, J12, J15 6 Header, 2.54mm, 3x1,
Gold, SMT
Header, 2.54mm, 3x1,
SMT
87898-0304 Molex
J7, J9, J11, J14, J16, J17 6 Header, 100mil, 2x1, Tin,
TH
Header, 2 PIN, 100mil,
Tin
PEC02SAAN Sullins Connector
Solutions
J13 1 Header (friction lock),
100mil, 4x1, R/A, TH
4x1 R/A Header 22/05/3041 Molex
J19 1 Header, 2.54mm, 10x2,
Tin, TH
Header, 10x2, 2.54mm,
TH
PEC10DAAN Sullins Connector
Solutions
J21 1 TERM BLOCK 3.5MM
VERT 4POS PCB
HDR4 OSTTE040161 On Shore Technology
J24 1 Receptacle, Micro-USB
Type B, 0.65 mm, 5x1,
R/A, Bottom Mount SMT
Receptacle, 0.65mm,
5x1, R/A, SMT
47346-1001 Molex
BQ76942EVM Circuit Module Physical Construction www.ti.com
32 BQ76942 Evaluation Module SLUUC32A – NOVEMBER 2019 – REVISED OCTOBER 2020
Submit Document Feedback
Copyright © 2020 Texas Instruments Incorporated
