5.2 Bill of Materials
The bill of materials for the circuit module is shown in Table 5-1. Substitute parts may be used in the manufacturing of the assembly.
Table 5-1. BQ76942 Circuit Module Bill of Materials
Designator Quantity Value Description Package Reference Part Number Manufacturer
!PCB1 1 Printed Circuit Board BMS028 Any
C1, C57 2 1uF CAP, CERM, 1 uF, 100 V,
+/- 10%, X7R, 1206
1206 C3216X7R2A105K160AA TDK
C2 1 100pF CAP, CERM, 100 pF, 100
V, +/- 5%, C0G/NP0,
AEC-Q200 Grade 1, 0603
603 GCM1885C2A101JA16D MuRata
C3 1 0.47uF CAP, CERM, 0.47 uF, 25
V, +/- 10%, X7R, AEC-
Q200 Grade 1, 0805
805 GCM219R71E474KA55D MuRata
C4, C5, C6, C7, C8, C9,
C12, C14, C15, C16, C18
11 0.22uF CAP, CERM, 0.22 uF, 50
V, +/- 10%, X7R, 0603
603 C1608X7R1H224K080AB TDK
C10, C13 2 1uF CAP, CERM, 1 uF, 16 V,
+/- 10%, X7R, 0805
805 EMK212B7105KG-T Taiyo Yuden
C11 1 0.022uF CAP, CERM, 0.022 uF, 16
V, +/- 10%, X7R, 0603
603 C0603C223K4RACTU Kemet
C17 1 0.01uF CAP, CERM, 0.01 uF, 16
V, +/- 10%, X7R, 0603
603 8.85012E+11 Wurth Elektronik
C19 1 2.2uF CAP, CERM, 2.2 uF, 16 V,
+/- 10%, X7R, 0805
805 EMK212B7225KG-T Taiyo Yuden
C21 1 100pF CAP, CERM, 100 pF, 50
V, +/- 5%, C0G/NP0,
0603
603 C0603C101J5GACTU Kemet
C22, C25, C26, C27,
C28, C30, C34, C36,
C38, C39, C40, C41,
C42, C43
14 0.1uF CAP, CERM, 0.1 uF, 50 V,
+/- 10%, X7R, 0603
603 8.85012E+11 Wurth Elektronik
C32, C33, C35, C37 4 0.1uF CAP, CERM, 0.1 uF, 100
V,+/- 10%, X7R, AEC-
Q200 Grade 1, 0603
603 GCJ188R72A104KA01D MuRata
C44, C45, C46, C48,
C51, C52, C54
7 0.1uF CAP, CERM, 0.1 uF, 16 V,
+/- 10%, X7R, 0402
402 8.85012E+11 Wurth Elektronik
C47, C53, C55 3 0.47uF CAP, CERM, 0.47 uF, 6.3
V, +/- 10%, X5R, 0402
402 04026D474KAT2A AVX
C49, C50 2 10uF CAP, CERM, 10 µF, 16
V,+/- 10%, X5R, 0805
805 CL21A106KOQNNNG Samsung Electro-
Mechanics
www.ti.com BQ76942EVM Circuit Module Physical Construction
SLUUC32A – NOVEMBER 2019 – REVISED OCTOBER 2020
Submit Document Feedback
BQ76942 Evaluation Module 31
Copyright © 2020 Texas Instruments Incorporated
