Table 5-1. BQ76942 Circuit Module Bill of Materials (continued)
Designator Quantity Value Description Package Reference Part Number Manufacturer
R50, R51 2 3.9k RES, 3.9 k, 5%, 1 W,
AEC-Q200 Grade 0, 2512
2512 CRCW25123K90JNEG Vishay-Dale
R52, R53, R59, R60, R61 5 10Meg RES, 10 M, 5%, 0.1 W,
AEC-Q200 Grade 0, 0603
603 CRCW060310M0JNEA Vishay-Dale
R54 1 36k RES, 36 k, 5%, 0.1 W,
AEC-Q200 Grade 0, 0603
603 CRCW060336K0JNEA Vishay-Dale
R55, R58 2 3.9k RES, 3.9 k, 5%, 0.25 W,
AEC-Q200 Grade 0, 1206
1206 CRCW12063K90JNEA Vishay-Dale
R63, R70, R72, R73, R74 5 5.1k RES, 5.1 k, 5%, 0.1 W,
AEC-Q200 Grade 0, 0603
603 CRCW06035K10JNEA Vishay-Dale
R66, R88, R89 3 0 RES, 0, 5%, 0.1 W, AEC-
Q200 Grade 0, 0603
603 CRCW06030000Z0EA Vishay-Dale
R76, R78, R81, R82,
R83, R84
6 5.1k RES, 5.1 k, 5%, 0.25 W,
AEC-Q200 Grade 0, 1206
1206 CRCW12065K10JNEA Vishay-Dale
R77 1 7.5k RES, 7.5 k, 5%, 0.1 W,
AEC-Q200 Grade 0, 0603
603 CRCW06037K50JNEA Vishay-Dale
R90, R91 2 33 RES, 33, 5%, 0.063 W,
AEC-Q200 Grade 0, 0402
402 CRCW040233R0JNED Vishay-Dale
R92 1 2.0k RES, 2.0 k, 5%, 0.063 W,
AEC-Q200 Grade 0, 0402
402 CRCW04022K00JNED Vishay-Dale
R93, R99 2 10k RES, 10 k, 5%, 0.063 W,
AEC-Q200 Grade 0, 0402
402 CRCW040210K0JNED Vishay-Dale
R94, R95 2 1.0Meg RES, 1.0 M, 5%, 0.063
W, AEC-Q200 Grade 0,
0402
402 CRCW04021M00JNED Vishay-Dale
R96, R97, R98 3 330 RES, 330, 1%, 0.1 W,
AEC-Q200 Grade 0, 0402
402 ERJ-2RKF3300X Panasonic
RT1, RT2 2 10k Thermistor NTC, 10.0k
ohm, 1%, Disc, 5x8.4 mm
Disc, 5x8.4 mm 103AT-2 SEMITEC Corporation
S1, S2 2 Switch, Tactile, SPST-NO,
SMT
Switch, 6.2X5X6.2 mm KST221JLFS C&K Components
S3 1 Switch, SPST-NO, Off-
Mom, 0.05A, 12VDC,
SMD
3.9x2.9mm PTS820 J20M SMTR LFS C&K Components
SH-J1, SH-J2, SH-J3,
SH-J4, SH-J5, SH-J6,
SH-J7, SH-J8, SH-J9,
SH-J10, SH-J11, SH-J12,
SH-J13, SH-J14, SH-J15
15 1x2 Shunt, 100mil, Gold
plated, Black
Shunt SNT-100-BK-G Samtec
