Table 5-1. BQ76942 Circuit Module Bill of Materials (continued)
Designator Quantity Value Description Package Reference Part Number Manufacturer
C23, C24, C29, C31 0 0.1uF CAP, CERM, 0.1 uF, 100
V,+/- 10%, X7R, AEC-
Q200 Grade 1, 0603
603 GCJ188R72A104KA01D MuRata
D11, D12, D13 0 100V Diode, Schottky, 100 V,
0.15 A, SOD-123
SOD-123 BAT46W-7-F Diodes Inc.
F1 0 Fuse, 30 A, 62 VDC,
SMD
9.5x2x5mm SFK-3030 Dexerials Corporation
FID1, FID2, FID3, FID4,
FID5, FID6
0 Fiducial mark. There is
nothing to buy or mount.
N/A N/A N/A
J20 0 Terminal Block, 3.5mm
Pitch, 2x1, TH
7.0x8.2x6.5mm ED555/2DS On-Shore Technology
J22 0 Header, 2.54 mm, 7x1,
Gold, TH
Header, 2.54 mm, 7x1,
TH
PBC07SAAN Sullins Connector
Solutions
J23 0 Header, 2.54 mm, 11x1,
Gold, TH
Header, 2.54 mm, 11x1,
TH
PBC11SAAN Sullins Connector
Solutions
J26 0 Header, 2.54mm, 5x1,
Tin, TH
Header, 2.54mm, 5x1, TH PEC05SAAN Sullins Connector
Solutions
Q2 0 -100V MOSFET, P-CH, -100 V,
-0.6 A, SOT-23
SOT-23 ZXMP10A13FTA Diodes Inc.
Q3 0 100V MOSFET, N-CH, 100 V,
10 A, DQJ0008A
(VSONP-8)
DQJ0008A CSD19534Q5A Texas Instruments
Q7 0 100V MOSFET, N-CH, 100 V,
17 A, DNK0008A (VSON-
CLIP-8)
DNK0008A CSD19532Q5B Texas Instruments
R4, R8 0 150 RES, 150, 5%, 1 W, AEC-
Q200 Grade 0, 2512
2512 CRCW2512150RJNEG Vishay-Dale
R13 0 0 RES, 0, 5%, 0.1 W, AEC-
Q200 Grade 0, 0603
603 CRCW06030000Z0EA Vishay-Dale
R44 0 4.7k RES, 4.7 k, 5%, 1 W,
AEC-Q200 Grade 0, 2512
2512 CRCW25124K70JNEG Vishay-Dale
R46 0 10Meg RES, 10 M, 5%, 0.1 W,
AEC-Q200 Grade 0, 0603
603 CRCW060310M0JNEA Vishay-Dale
R56 0 0 RES, 0, 5%, 2 W, 2512
WIDE
2512 WIDE RCL12250000Z0EG Vishay Draloric
R65 0 51 RES, 51, 5%, 0.1 W,
AEC-Q200 Grade 0, 0603
603 CRCW060351R0JNEA Vishay-Dale
BQ76942EVM Circuit Module Physical Construction www.ti.com
36 BQ76942 Evaluation Module SLUUC32A – NOVEMBER 2019 – REVISED OCTOBER 2020
