10 LMP90100 EVB User’s Guide August 2012
4.0. Example #2: Shorted Input and Calibration Test
This example demonstrates LMP90100’s ability to calibrate for offset error.
A. LMP90100 EB Jumper Connections
1. Connect the LMP90100EB jumpers like the jumpers shown in the figure and table below.
Jumpers not mentioned can be left unconnected.
2. The SPIO-4 board is properly setup out of the box (no assembly required).
3. The schematic for the LMP90100EB can be seen in section 10.
Figure 8 – LMP90100EB Jumper Settings for the Shorted input and Calibration Test
