Appendix A
Table A-2. BSL Version 1.30 on F41x, F11x, and F11x1
F11x (obsolete)
Device F14x
F11x1A
BSL Version 1.30
Cold start 0C00h
BSL vector address
Warm start 0C02h
Chip ID address 0FF0h
Chip ID data F143h F112h
BSL version address 0FFAh
BSL version data 0130h
Mass erase time, nominal (ms) 206.4
0000h–00FFh Byte
Read/write access at
0100h–FFFEh Word
Verification during write (online) No
Cold start 0220h
Stack pointer initialization
Warm start Unchanged
Resources Used by BSL
Transmit pin (TX) P 1.0 P 1.1
Receive pin (RX) P2.1 P2.2
RAM/stack used 0200h–021Fh
Working registers R5–R9
System clock, affected controls SCFI0, SCFI1, SCFQCTL BCSCTL1, DCOCTL
Timer_A, affected controls TACTL, TAR, CCTL0, CCR0
mov #00h, &CCTL0
mov #00h, &CCTL0
mov.b #00h, &BCSCTL2
Preparation for SW call
mov.b #00h, &FLLCTL1
mov #00h, SR
br &0C00h
br &0C00h
SLAA089D – December 1999 – Revised August 2006 Features of the MSP430 Bootstrap Loader 17
Submit Documentation Feedback
