TAS5707, TAS5707A
www.ti.com
SLOS556B NOVEMBER 2008REVISED NOVEMBER 2009
SERIAL DATA INTERFACE REGISTER (0x04)
As shown in Table 9, the TAS5707 supports 9 serial data modes. The default is 24-bit, I
2
S mode,
Table 9. Serial Data Interface Control Register (0x04) Format
RECEIVE SERIAL DATA WORD
D7–D4 D3 D2 D1 D0
INTERFACE FORMAT LENGTH
Right-justified 16 0000 0 0 0 0
Right-justified 20 0000 0 0 0 1
Right-justified 24 0000 0 0 1 0
I
2
S 16 000 0 0 1 1
I
2
S 20 0000 0 1 0 0
I
2
S
(1)
24 0000 0 1 0 1
Left-justified 16 0000 0 1 1 0
Left-justified 20 0000 0 1 1 1
Left-justified 24 0000 1 0 0 0
Reserved 0000 1 0 0 1
Reserved 0000 1 0 1 0
Reserved 0000 1 0 1 1
Reserved 0000 1 1 0 0
Reserved 0000 1 1 0 1
Reserved 0000 1 1 1 0
Reserved 0000 1 1 1 1
(1) Default values are in bold.
Copyright © 2008–2009, Texas Instruments Incorporated Submit Documentation Feedback 39
Product Folder Link(s): TAS5707 TAS5707A
