MODULATION LIMIT REGISTER (0x10)
The modulation limit is the maximum duty cycle of the PWM output waveform.
Table 15. Modulation Limit Register (0x10)
D7 D6 D5 D4 D3 D2 D1 D0 MODULATION LIMIT
– – – – – 0 0 0 99.2%
– – – – – 0 0 1 98.4%
– – – – – 0 1 0 97.7%
– – – – – 0 1 1 96.9%
– – – – – 1 0 0 96.1%
– – – – – 1 0 1 95.3%
– – – – – 1 1 0 94.5%
– – – – – 1 1 1 93.8%
0 0 0 0 0 – – – RESERVED
INTERCHANNEL DELAY REGISTERS (0x11, 0x12, 0x13, and 0x14)
Internal PWM channels 1, 2, 1, and 2 are mapped into registers 0x11, 0x12, 0x13, and 0x14.
Table 16. Channel Interchannel Delay Register Format
BITS DEFINITION D7 D6 D5 D4 D3 D2 D1 D0 FUNCTION
0 0 0 0 0 0 – – Minimum absolute delay, 0 DCLK cycles
0 1 1 1 1 1 – – Maximum positive delay, 31 × 4 DCLK cycles
1 0 0 0 0 0 – – Maximum negative delay, –32 × 4 DCLK cycles
0 0 RESERVED
SUBADDRESS D7 D6 D5 D4 D3 D2 D1 D0 Delay = (value) × 4 DCLKs
0x11 1 0 1 0 1 1 – – Default value for channel 1
(1)
0x12 0 1 0 1 0 1 – – Default value for channel 2
(1)
0x13 1 0 1 0 1 1 – – Default value for channel 1
(1)
0x14 0 1 0 1 0 1 – – Default value for channel 2
(1)
(1) Default values are in bold.
ICD settings have high impact on audio performance (e.g., dynamic range, THD, crosstalk etc.) Therefore,
appropriate ICD settings must be used. By default, the device has ICD settings for AD mode. If used in BD
mode, then update these registers before coming out of all-channel shutdown.
REGISTER AD MODE BD MODE
0x11 0xAC 0xB8
0x12 0x54 0x60
0x13 0xAC 0xA0
0x14 0x54 0x48
