TAS5707, TAS5707A
www.ti.com
SLOS556B –NOVEMBER 2008–REVISED NOVEMBER 2009
PLL INPUT PARAMETERS AND EXTERNAL FILTER COMPONENTS
PARAMETER TEST CONDITIONS MIN TYP MAX UNIT
f
MCLKI
MCLK Frequency 2.8224 24.576 MHz
MCLK duty cycle 40% 50% 60%
tr /
Rise/fall time for MCLK 5 ns
tf
(MCLK)
LRCLK allowable drift before LRCLK reset 4 MCLKs
External PLL filter capacitor C1 SMD 0603 Y5V 47 nF
External PLL filter capacitor C2 SMD 0603 Y5V 4.7 nF
External PLL filter resistor R SMD 0603, metal film 470 Ω
ELECTRICAL CHARACTERISTICS
DC Characteristics
TA = 25°, PVCC_X = 18V, DVDD = AVDD = 3.3V, R
L
= 8Ω, BTL AD Mode, FS = 48KHz (unless otherwise noted)
PARAMETER TEST CONDITIONS MIN TYP MAX UNIT
V
OH
High-level output voltage FAULTZ and SDA I
OH
= –4 mA 2.4 V
DVDD = AVDD = 3 V
V
OL
Low-level output voltage FAULTZ and SDA I
OL
= 4 mA 0.5 V
DVDD = AVDD = 3 V
V
I
< V
IL
; DVDD = AVDD 75
I
IL
Low-level input current μA
= 3.6V
V
I
> V
IH
; DVDD = 75
I
IH
High-level input current μA
AVDD = 3.6V
Normal Mode 48 83
3.3 V supply voltage (DVDD,
I
DD
3.3 V supply current mA
Reset (RESET = low, 24 32
AVDD)
PDN = high)
Normal Mode 30 55
I
PVDD
Half-bridge supply current No load (PVDD_X) mA
Reset (RESET = low, 5 13
PDN = high)
Drain-to-source resistance, LS T
J
= 25°C, includes metallization resistance 180
r
DS(on)
(1)
mΩ
Drain-to-source resistance,
T
J
= 25°C, includes metallization resistance 180
HS
I/O Protection
V
uvp
Undervoltage protection limit PVDD falling 7.2 V
V
uvp,hyst
Undervoltage protection limit PVDD rising 7.6 V
OTE
(2)
Overtemperature error 150 °C
Extra temperature drop
OTE
HYST
(2)
30 °C
required to recover from error
OTW Overtemperature warning 125 °C
Temperature drop required to
OTW
HYST
25 °C
recover from warning
OLPC Overload protection counter f
PWM
= 384 kHz 0.63 ms
I
OC
Overcurrent limit protection Resistor—programmable, max. current, R
OCP
= 22 kΩ 4.5 A
I
OCT
Overcurrent response time 150 ns
OC programming resistor Resistor tolerance = 5% for typical value; the minimum
R
OCP
20 22 kΩ
range resistance should not be less than 20 kΩ.
Internal pulldown resistor at Connected when drivers are tristated to provide bootstrap
R
PD
3 kΩ
the output of each half-bridge capacitor charge.
(1) This does not include bond-wire or pin resistance.
(2) Specified by design
Copyright © 2008–2009, Texas Instruments Incorporated Submit Documentation Feedback 9
Product Folder Link(s): TAS5707 TAS5707A
