TAS5707, TAS5707A
SLOS556B –NOVEMBER 2008–REVISED NOVEMBER 2009 www.ti.com
BANK SWITCH AND EQ CONTROL (0x50)
Table 23. Bank Switching Command
D31 D30 D29 D28 D27 D26 D25 D24 FUNCTION
0 – – – – – – – 32 kHz, does not use bank 3
(1)
1 – – – – – – – 32 kHz, uses bank 3
– 0 – – – – – – Reserved
(1)
– – 0 – – – – – Reserved
(1)
– – – 0 – – – – 44.1/48 kHz, does not use bank 3
(1)
– – – 1 – – – – 44.1/48 kHz, uses bank 3
– – – – 0 – – – 16 kHz, does not use bank 3
– – – – 1 – – – 16 kHz, uses bank 3
(1)
– – – – – 0 – – 22.025/24 kHz, does not use bank 3
– – – – – 1 – – 22.025/24 kHz, uses bank 3
(1)
– – – – – – 0 – 8 kHz, does not use bank 3
– – – – – – 1 – 8 kHz, uses bank 3
(1)
– – – – – – – 0 11.025 kHz/12, does not use bank 3
– – – – – – – 1 11.025/12 kHz, uses bank 3
(1)
D23 D22 D21 D20 D19 D18 D17 D16 FUNCTION
0 – – – – – – – 32 kHz, does not use bank 2
(1)
1 – – – – – – – 32 kHz, uses bank 2
– 1 – – – – – – Reserved
(1)
– – 1 – – – – – Reserved
(1)
– – – 0 – – – – 44.1/48 kHz, does not use bank 2
– – – 1 – – – – 44.1/48 kHz, uses bank 2
(1)
– – – – 0 – – – 16 kHz, does not use bank 2
(1)
– – – – 1 – – – 16 kHz, uses bank 2
– – – – – 0 – – 22.025/24 kHz, does not use bank 2
(1)
– – – – – 1 – – 22.025/24 kHz, uses bank 2
– – – – – – 0 – 8 kHz, does not use bank 2
(1)
– – – – – – 1 – 8 kHz, uses bank 2
– – – – – – – 0 11.025/12 kHz, does not use bank 2
(1)
– – – – – – – 1 11.025/12 kHz, uses bank 2
D15 D14 D13 D12 D11 D10 D9 D8 FUNCTION
0 – – – – – – – 32 kHz, does not use bank 1
1 – – – – – – – 32 kHz, uses bank 1
(1)
– 0 – – – – – – Reserved
(1)
– – 0 – – – – – Reserved
(1)
– – – 0 – – – – 44.1/48 kHz, does not use bank 1
(1)
– – – 1 – – – – 44.1/48 kHz, uses bank 1
– – – – 0 – – – 16 kHz, does not use bank 1
(1)
– – – – 1 – – – 16 kHz, uses bank 1
– – – – – 0 – – 22.025/24 kHz, does not use bank 1
(1)
– – – – – 1 – – 22.025/24 kHz, uses bank 1
– – – – – – 0 – 8 kHz, does not use bank 1
(1)
– – – – – – 1 – 8 kHz, uses bank 1
– – – – – – – 0 11.025/12 kHz, does not use bank 1
(1)
– – – – – – – 1 11.025/12 kHz, uses bank 1
(1) Default values are in bold.
48 Submit Documentation Feedback Copyright © 2008–2009, Texas Instruments Incorporated
Product Folder Link(s): TAS5707 TAS5707A
