TAS5707, TAS5707A
www.ti.com
SLOS556B –NOVEMBER 2008–REVISED NOVEMBER 2009
Table 23. Bank Switching Command (continued)
D7 D6 D5 D4 D3 D2 D1 D0 FUNCTION
0 EQ ON
1 – – – – – – – EQ OFF (bypass BQ 0-6 of channels 1 and 2)
– 0 – – – – – – Reserved
(2)
– – 0 – – – – – Ignore bank-mapping in bits D31–D8.Use default mapping.
(2)
1 Use bank-mapping in bits D31–D8.
– – – 0 – – – – L and R can be written independently.
(2)
L and R are ganged for EQ biquads; a write to Left channel BQ is
– – – 1 – – – –
also written to Right channel BQ. (0X29-2F is ganged to 0X30-0X36).
– – – – 0 – – – Reserved
(2)
– – – – – 0 0 0 No bank switching. All updates to DAP
(2)
– – – – – 0 0 1 Configure bank 1 (32 kHz by default)
– – – – – 0 1 0 Configure bank 2 (44.1/48 kHz by default)
– – – – – 0 1 1 Configure bank 3 (other sample rates by default)
– – – – – 1 0 0 Automatic bank selection
– – – – – 1 0 1 Reserved
– – – – – 1 1 X Reserved
(2) Default values are in bold.
Copyright © 2008–2009, Texas Instruments Incorporated Submit Documentation Feedback 49
Product Folder Link(s): TAS5707 TAS5707A
