*All dimensions are nominal
Device Package Type Package Drawing Pins SPQ Length (mm) Width (mm) Height (mm)
TAS5707APHPR HTQFP PHP 48 1000 367.0 367.0 38.0
TAS5707APHPR HTQFP PHP 48 1000 336.6 336.6 31.8
TAS5707PHPR HTQFP PHP 48 1000 367.0 367.0 38.0
TAS5707PHPR HTQFP PHP 48 1000 336.6 336.6 31.8
PACKAGE MATERIALS INFORMATION
www.ti.com 30-Mar-2017
Pack Materials-Page 2
