Texas Instruments TAS6584-Q1 EVM User Manual

Table 3-1. Bill of Materials (continued)
Designator Qty Value Description PackageReference PartNumber Manufacturer
(1)
Alternate PartNumber
R33 1 680 RES, 680, 1%, 0.1 W, 0603 603 RC0603FR-07680RL Yageo
R35 1 0 RES, 0, 5%, 0.05 W, AEC-Q200 Grade 1, 0201 201 ERJ-1GN0R00C Panasonic
R36 1 43.2 RES, 43.2, 1%, 0.1 W, 0603 603 RC0603FR-0743R2L Yageo
R37, R38, R40, R43 4 10.0k RES, 10.0 k, 1%, 0.05 W, 0201 201 RC0201FR-0710KL Yageo America
R42 1 25.5k RES, 25.5 k, 1%, 0.05 W, 0201 201 RC0201FR-0725K5L Yageo America
R44 1 51.0k RES, 51.0 k, 1%, 0.05 W, 0201 201 RC0201FR-0751KL Yageo America
R46 1 4.70k RES, 4.70 k, 0.5%, 0.1 W, 0603 603 RT0603DRE074K7L Yageo America
R47 1 24.0k RES, 24.0 k, 1%, 0.1 W, 0603 603 RC0603FR-0724KL Yageo
R52 1 200k RES, 200 k, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 603 CRCW0603200KFKEA Vishay-Dale
R56 1 100 RES, 100, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 603 CRCW0603100RFKEA Vishay-Dale
R57 1 2.00k RES, 2.00 k, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 603 CRCW06032K00FKEA Vishay-Dale
R58 1 75 RES, 75.0, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 603 CRCW060375R0FKEA Vishay-Dale
R59, R60, R61, R62, R64, R65,
R69
7 49.9 RES, 49.9, 1%, 0.063 W, AEC-Q200 Grade 0,
0402
402 CRCW040249R9FKED Vishay-Dale
R63 1 470 RES, 470, 1%, 0.1 W, 0603 603 RC0603FR-07470RL Yageo
R67 1 100 RES, 100, 1%, 0.1 W, 0402 402 ERJ-2RKF1000X Panasonic
R70 1 681 RES, 681, 1%, 0.063 W, AEC-Q200 Grade 0, 0402 402 CRCW0402681RFKED Vishay-Dale
R71 1 100k RES, 100 k, 1%, 0.063 W, AEC-Q200 Grade 0,
0402
402 CRCW0402100KFKED Vishay-Dale
R74 1 10.0k RES, 10.0 k, 1%, 0.063 W, AEC-Q200 Grade 0,
0402
402 CRCW040210K0FKED Vishay-Dale
S1, S2, S3, S4 4 Switch, SPDT, On-On, 1 Pos, 0.4A, 28 VDC, TH 5.6x5.4mm FT1D-4M-Z Copal Electronics
SH-J1, SH-J2, SH-J3, SH-J4, SH-
J5, SH-J6, SH-J7, SH-J8, SH-J9,
SH-J10, SH-J11, SH-J12, SH-J13,
SH-J14
14 1x2 Shunt, 100mil, Gold plated, Black Shunt SNT-100-BK-G Samtec 969102-0000-DA
TP1, TP2, TP3, TP4, TP5, TP6,
TP7, TP8
8 Test Point, Miniature, Orange, TH Orange Miniature Testpoint 5003 Keystone
U1 1 20W Inductor-Less, Digital Input, Stereo, Closed-
Loop Class-D Audio Amplifier with Enhanced
Processing and DirectPath HP Driver (DCP0038)
QFP64-PHD TAS6584Q1PHD Texas Instruments
U3, U9 2 Single Inverter Gate, DRL0005A, LARGE T&R DRL0005A SN74LVC1GU04DRLR Texas Instruments
U4 1 IC MCU 512KB RAM, 128TQFP TQFP-128 XEF216-512-TQ128-C20A XMOS semiconductor
U5 1 Single-Channel Ultra-Small Adjustable Supervisory
Circuit With Active-High Open-Drain Output,
DRY0006A (USON-6)
DRY0006A TPS3897ADRYR Texas Instruments
U6 1 Enhanced Product Dual Buffer/Driver with Open-
Drain Output, DCK0006A (SOT-SC70-6)
DSF0006A SN74LVC2G07DSFR Texas Instruments
U7 1 Programmable 1-PLL VCXO Clock Synthesizer
with 2.5-V or 3.3-V LVCMOS Outputs, PW0014A
(TSSOP-14)
PW0014A CDCE913PWR Texas Instruments CDCE913PW
U8 1 Dual-Bit Dual-Supply Bus Transceiver, DQM0008A
(X2SON-8)
DQM0008A SN74AVC2T244DQMR Texas Instruments
U10 1 Photolink- Fiber Optic Receiver, TH 13.5x10x9.7mm FCR684208R CLIFF Electronic Components
Ltd
U11, U12, U14, U15 4 Single 2-Line to 1-Line Data Selector/Multiplexer,
DCU0008A, LARGE T&R
DCU0008A SN74LVC2G157DCUR Texas Instruments SN74LVC2G157DCUT
TI Confidential - Maximum Restrictions
www.ti.com Schematic and Bill of Materials
SLOU527 – DECEMBER 2021
Submit Document Feedback
TAS6584-Q1 EVM User's Guide 19
Copyright © 2021 Texas Instruments Incorporated
